Mobile asphalt plants come with some inherent advantages over their stationary counterpart, and size and features like additional portability are not the only ones. Despite their compact design and size, these plants often mimic the capacities of their bigger cousins.
With mobile drum mix plants, the components are preassembled on a maximum of three or four chassis. The number of chassis can vary depending on the configuration. All of these chassis are prewired with a separate junction box and is equipped with safety lights, king pin, pneumatic braking axles and tire covers.
It goes without saying that the portable asphalt drums are about as powerful and productive as the stationary ones. The main added advantage they have is of the mobility over the stationary drum mixers.
The featuring tire, tubes and wheels rims can either be supplied by Atlas Technologies or procured by the customers according to their preferences.
Advantages That Put a Portable Asphalt Plant ahead of a Stationary One
The portable asphalt plants have a distinct set of advantages over the stationary models. Here are a few:
• Foundation-free or very little foundation – This allows to set up the machine in quick time.
• Easy and quick installation and commission – This ensures that the plant can be setup and made to run in a quick time.
• The standard model is fitted with 3 to 4 chassis – Same number of chassis like a stationary plant meaning no increase in the transportation cost.
• The plants are built on a structure that is hardy and rugged – Heavy units allow long range transportation and save costs.
• Storage silos available with all models – This feature allows the customer to go with any configuration and have that extra liberty.
• Customizable bitumen storage tanks – Bitumen storage tanks are fully customized and available in different sizes to suit customers’ requirements – all fully mobile.
• Drying/mixing drum and venture type dust collector are both bolted together for an easy and instant installation – This is to lower the transportation cost when the equipment is inside the container or when it is moved by a prime mover.
Chassis Arrangement in Mobile Drum Mix Plant DM 45 of 40 to 60 tph Capacity
Atlas DM 45 is a medium sized drum mixer plant. The compact size and smart chassis arrangement ensure minimum transportation costs for the customer. It comes with a full-fledged 4 bin feeder unit to take on all the jobs with ease. It is a compact and effectively sized plant. Here is the chassis arrangement of the above plant:
• The feeder is on one of the chassis that has a single axle.
• One another chassis with two axles is the drying/mixing drum that is outfitted with a pollution control device.
• On the third and last chassis are the fuel tank that is connected to the dryer burner, the mineral filler and the bitumen tank.
All units come pre-wired with junction boxes, tyres, tubes and wheel hubs. Also the units are towable by a prime mover by a king pin system.
Chassis Arrangement of Mobile Drum Mix Plant DM 50 of 60 to 90 tph Capacity and for DM 60 of 90-120 tph
The models ranging in capacities 60-90 tph and 90-120 tph and bigger plants are more suited for medium to heavy jobs. They are fully mobile and feature loaded for mobility. Below is the configuration of the mobile drum mix plant fix of the said capacities:
• The feeder is located on a single axle chassis.
• The drying and mixing drum is set on another chassis with twin axles. The unit comes pre-fitted with a pollution control system.
• On the third chassis is the fuel tank, mineral filler and bitumen tank of standard 20T.
• On the last chassis sits the control cabin separately.
It is noteworthy that all the units of Atlas mobile asphalt drum mix plants come pre-wired with tyres, tubes, wheel hubs and junction boxes. Each chassis are towable by a prime mover by a king pin.
Atlas Technologies manufactures a wide range of mobile asphalt plants. On its catalogue are plants of varying sizes, designs and capacities manufactured to cater to specific sets of needs. We do have mobile asphalt batch type plants. Contact us to know more.
